50W Constant Current Type YSL60-D
Dimming LED Power Supply
– Universal Input: 90-265V AC 50/60Hz
– RoHS Compliance
– EMI Standard EN55015
– Safety Standard: EN61347-1, EN61347-2-13, UL8750
– Inrush current<65A AC230V/50Hz – High efficiency & low power consumption
– Short Circuit, Over Current and Over Voltage Protection
– Over temperature protection
– 100% full load burn-in test
– Dimming available
Triac Dimming
Constant Current
Model | Power (max.) | Input Voltage | Output Current | Output Voltage (max.) | PF | Voltage Tolerance | Efficiency | Dimension(LxWxH) |
YSL60-D | 45W | 230V/120V AC | 500mA | 60V | ≥0.9 | ±5% | 85% | 160x58x20mm |
YSL60-D | 45W | 230V/120V AC | 700mA | 42V | ≥0.9 | ±5% | 85% | 160x58x20mm |
YSL60-D | 45W | 230V/120V AC | 1050mA | 28V | ≥0.9 | ±5% | 85% | 160x58x20mm |
0-10V Dimming
Constant Current
Model | Power (max.) | Input Voltage | Output Current | Output Voltage (max.) | PF | Voltage Tolerance | Efficiency | Dimension(LxWxH) |
YSL60-D | 50W | 230V/120V AC | 1050mA | 71V | ≥0.9 | ±5% | 85% | 160x58x20mm |
YSL60-D | 50W | 230V/120V AC | 1400mA | 47V | ≥0.9 | ±5% | 85% | 160x58x20mm |
YSL60-D | 50W | 230V/120V AC | 2100mA | 35V | ≥0.9 | ±5% | 85% | 160x58x20mm |
