150W Constant Current Type YSL150-150
Universal Input: 90-265V AC 50/60Hz
RoHS Compliance
EMI Standard EN55015
Safety Standard: EN61347-1, EN61347-2-13, UL8750
Inrush current<65A, 230VAC/50Hz
High efficiency & low power consumption
Short Circuit, Over Current and Over Voltage Protection
Over temperature protection
100% full load burn-in test
Auto restart after remove of fault conditions
Constant Current
Model | Power (max.) | Input Voltage | Output Current | Output Voltage (max.) | PF | Voltage Tolerance | Efficiency | Dimension(LxWxH) |
YSL150-2000 | 150W | 220-240V AC | 1400mA | 100V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-2400 | 150W | 220-240V AC | 2100mA | 83V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-3600 | 150W | 220-240V AC | 3600mA | 55V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-4200 | 150W | 220-240V AC | 4800mA | 47V | ≥0.95 | ±5% | 92% | 205x71x35mm |
Model | Power (max.) | Input Voltage | Output Current | Output Voltage (max.) | PF | Voltage Tolerance | Efficiency | Dimension(LxWxH) |
YSL150-1400 | 150W | 90-265V AC | 1400mA | 107V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-2100 | 150W | 90-265V AC | 2100mA | 71V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-3600 | 150W | 90-265V AC | 3600mA | 41V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-4200 | 150W | 90-265V AC | 4200mA | 35V | ≥0.95 | ±5% | 92% | 205x71x35mm |
