200W Constant Current Type YSL150-200
– Universal Input: 90-265V AC 50/60Hz
– RoHS Compliance
– EMI Standard EN55015
– Safety Standard: EN61347-1, EN61347-2-13, UL8750
– Inrush current<65A AC230V/50Hz – High efficiency & low power consumption
– Short Circuit, Over Current and Over Voltage Protection
– Over temperature protection
– 100% full load burn-in test
– Auto restart after remove of fault conditions
Model | Power (max.) | Input Voltage | Output Current | Output Voltage (max.) | PF | Voltage Tolerance | Efficiency | Dimension(LxWxH) |
YSL150-2000 | 200W | 220-240V AC | 2000mA | 100V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-2400 | 200W | 220-240V AC | 2400mA | 83V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-3600 | 200W | 220-240V AC | 3600mA | 55V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-4200 | 200W | 220-240V AC | 4800mA | 47V | ≥0.95 | ±5% | 92% | 205x71x35mm |
Model | Power (max.) | Input Voltage | Output Current | Output Voltage (max.) | PF | Voltage Tolerance | Efficiency | Dimension(LxWxH) |
YSL150-2000 | 200W | 90-265V AC | 2000mA | 100V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-2400 | 200W | 90-265V AC | 2400mA | 83V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-3600 | 200W | 90-265V AC | 3600mA | 55V | ≥0.95 | ±5% | 92% | 205x71x35mm |
YSL150-4200 | 200W | 90-265V AC | 4200mA | 47V | ≥0.95 | ±5% | 92% | 205x71x35mm |
